GPU comparison with benchmarksThe PNY GeForce RTX 4090 24GB VERTO Triple Fan has 16384 shader units and these clock a maximum of 2.52 GHz which results in an FP32 computing power of 82.58 TFLOPS.
The GIGABYTE Radeon Pro W7900 has 6144 shader units and these clock at a maximum of 2.50 GHz and achieve an FP32 computing power of 61.32 TFLOPS. |
||
GPUThe PNY GeForce RTX 4090 24GB VERTO Triple Fan is equipped with a graphics chip of the Ada Lovelace architecture, which has 128 streaming multiprocessors. The graphics card GIGABYTE Radeon Pro W7900 is based on the RDNA 3 architecture and is equipped with 96 execution units. |
||
PNY GeForce RTX 4090 24GB VERTO Triple Fan | GPU | GIGABYTE Radeon Pro W7900 |
NVIDIA GeForce RTX 4090 | Based on | AMD Radeon Pro W7900 |
AD102-300-A1 | GPU Chip | Navi 31 |
Ada Lovelace | Architecture | RDNA 3 |
128 | Streaming Multiprocessors | 96 |
16384 | Shader | 6144 |
176 | Render Output Units | 192 |
512 | Texture Units | 384 |
128 | Raytracing Cores | 96 |
MemoryThe PNY GeForce RTX 4090 24GB VERTO Triple Fan is equipped with a 24 GB large GDDR6X graphics memory, which is equipped with 1.313 GHz clocks. The GIGABYTE Radeon Pro W7900 has a 48 GB large GDDR6 graphics memory and the memory clock is 2.250GHz. |
||
24 GB | Memory Size | 48 GB |
GDDR6X | Memory Type | GDDR6 |
1.313 GHz | Memory Clock | 2.250 GHz |
21.0 Gbps | Memory Speed | 18.0 Gbps |
1008 GB/s | Memory bandwidth | 864 GB/s |
384 bit | Memory Interface | 384 bit |
Clock SpeedsThe PNY GeForce RTX 4090 24GB VERTO Triple Fan has a turbo clock of 2.520 GHz. The turbo frequency of the GIGABYTE Radeon Pro W7900 is 2.495 GHz. |
||
2.235 GHz | Base Clock | 1.855 GHz |
2.520 GHz | Boost Clock | 2.495 GHz |
Avg (Game) Clock | ||
Yes | Overclocking | Yes |
Thermal DesignThe PNY GeForce RTX 4090 24GB VERTO Triple Fan has 1 x 16-Pin connectors through which it is supplied with power. The manufacturer specifies the maximum operating temperature of the graphics card as 90 °C. The GIGABYTE Radeon Pro W7900 is equipped with a 2 x 8-Pin PCIe power connector that supplies it with power. The maximum operating temperature of the card is 99 °C. |
||
450 W | TDP | 295 W (Reference) |
-- | TDP (up) | -- |
90 °C | Tjunction max | 99 °C |
1 x 16-Pin | PCIe-Power | 2 x 8-Pin |
Cooler & FansThe graphics processor and graphics memory of the PNY GeForce RTX 4090 24GB VERTO Triple Fan are cooled with a Air cooling. The GIGABYTE Radeon Pro W7900 is cooled by a Air cooling. |
||
Axial | Fan-Type | Radial |
3 x 100 mm | Fan 1 | 1 x 75 mm |
-- | Fan 2 | -- |
Air cooling | Cooler-Type | Air cooling |
0 dB | Noise (Idle) | 0 dB |
-- | Noise (Load) | -- |
ConnectivityThe PNY GeForce RTX 4090 24GB VERTO Triple Fan supports the downward compatible copy protection HDCP in version 2.3. The GIGABYTE Radeon Pro W7900 supports HDCP in version 2.3 and all previous versions. |
||
4 | Max. Displays | 4 |
2.3 | HDCP-Version | 2.3 |
1x HDMI v2.1 | HDMI Ports | -- |
3x DP v1.4a | DP Ports | 4x DP v2.1 |
-- | DVI Ports | -- |
-- | VGA Ports | -- |
-- | USB-C Ports | -- |
FeaturesetThe PNY GeForce RTX 4090 24GB VERTO Triple Fan supports the DirectX standard from Microsoft in version 12_2 (Ultimate). The GIGABYTE Radeon Pro W7900 supports Microsoft's DirectX version 12_2 (Ultimate). |
||
7680x4320 | Max. resolution | 7680x4320 |
12_2 (Ultimate) | DirectX | 12_2 (Ultimate) |
Yes | Raytracing | Yes |
Yes | DLSS / FSR | Yes |
No LED lighting | LED | No LED lighting |
Supported Video CodecsThis area lists which video codecs can be decoded or encoded by the graphics cards in hardware. As a result, the power consumption can be reduced due to a lower processor load. |
||
Decode / Encode | h264 | Decode / Encode |
Decode / Encode | h265 / HEVC | Decode / Encode |
Decode | AV1 | Decode / Encode |
Decode | VP8 | Decode / Encode |
Decode | VP9 | Decode / Encode |
DimensionsThe PNY GeForce RTX 4090 24GB VERTO Triple Fan is 59 mm wide and therefore needs the space of 2 PCIe-Slots in the case. The width of the GIGABYTE Radeon Pro W7900 is 59 mm and thus requires the space of 2 PCIe-Slots in the PC case. |
||
337 mm | Length | 293 mm |
143 mm | Height | 126 mm |
59 mm | Width | 42 mm |
3 PCIe-Slots | Width (Slots) | 2 PCIe-Slots |
-- | Weight | -- |
PCIe 4.0 x 16 | GPU Interface | PCIe 4.0 x 16 |
No | SFF-Ready | No |
Additional dataManufactured using the 5 nanometer process, PNY GeForce RTX 4090 24GB VERTO Triple Fan was released in Q4/2022. The GIGABYTE Radeon Pro W7900 published in Q2/2024 is manufactured with a structure width of 5 nanometers. |
||
VCG409024TFXPB1 | Part-no | W7900 AI TOP 48G |
Q4/2022 | Release date | Q2/2024 |
1,599 $ (Reference) | Launch Price | 3,999 $ |
5 nm | Structure size | 5 nm |
data sheet | Documents | data sheet |
![]() |
